A 5 line major efficiency hack for your GraphQL API Type resolvers

Using Apollo Server and Postgres — Sequelize, we’ll create a proof of concept exploiting the info parameter of the resolver function for a 94% reduction in database load on Type queries*.

If you are already familiar with the Apollo Server resolver signature and its info parameter and want to skip to the hack, click here. Thanks to my inquisitive friend Sloan Brantley Gwaltney for tipping me off to the info parameter’s potential.

Background — The resolver function signature

Apollo Server provides the following resolver function signature from their docs:

fieldName(obj, args, context, info) { result }

Back in April, I wrote some notes on the signature to teach to some teammates who were new to GraphQL / Apollo Server. Below is my (slightly) modified version of the signature:

(instance, arguments, context, info) { ...returning data... }

instance

obj / root / instance
 — GraphQL Type associated with the resolver
 — only used in Type custom field resolvers (for other Types / renamed fields)
 — exists as an instance of the Type’s corresponding database Model

ex: Type: User Model: User, instance is ‘user’ Type custom field resolver:  user => user.property/.relationshipGetter()

arguments

arguments / Input object
 — arguments to the Query or Mutation
 — typically in the form of an Input Type object [defined in the Schema]
 — Inputs are reusable objects that may contain many fields, a subset of which are appropriate for each resolver
 — flexible inputs that can be used for both Query and Mutation resolvers
 — destructuring in the resolver allows selectivity of the Input object fields

ex: UserInput: { id, username, avatar, githubID }  resolver: (root, { id }) => User.findById(id); // destructures 1 of 4 UserInput fields

context

context / ctx
 — the context object is injected at runtime in the Apollo middleware declaration of app.js
 — it is the most versatile of the resolver parameters
 — allows you to pass in things like utility functions, database models, authenticated User, and so on
 — by passing these in the context, you no longer need ‘require’ statements for models and helpers. They are accessible directly from the resolver.
 — typically defined as a nesting object with each subcontext having its own object

info

no idea?

…That was until a serendipitous conversation with Sloan led to discussing this useless parameter. Sloan mentioned that it contained information about the incoming Query. This got my gears turning on improving resolver efficiency.

The info parameter

The info object holds details about your entire API Schema and other bits that I assume Apollo Server uses for processing. In particular, it holds information about the Query itself — specifically the set of Type fields requested.

Sequelize and the Tale of Gross Inefficiency

As it turns out, when Sequelize (and I believe every other OR/DM*) resolves rows or documents, it does so in their entirety. On the front / receiving end the data is indeed trimmed to specifications. But on the back end, the process appears to be:

DB query for entire row/doc → map / custom resolver requested fields → filter data and resolve requested fields

This was proven with a Postgres echo I ran from Sequelize on a User query:

SELECT "id", "role", "email", ...wtf Sequelize..., "timezone", "country_id", "city_id", "created_at", "updated_at" FROM "users" AS "User" WHERE "User"."github_username" = 'the-vampiire' LIMIT 1;

The Postgres query selects all 17 fields while the API Query itself only requests 1:

user(username:”the-vampiire”) { id }

Digging Into the info Object

With a bit of digging into the info object, I was able to get to my target: the requested fields. My theory was that if I knew the fields, I could pass them in as the attributes property of the Sequelize query object to reduce the load on the Postgres server.

info.fieldNodes[].selectionSet.selections[].name.value

notes

• fieldNodes is an array with the 0th element is the first query. My guess is that it’s an array to support batch queries.
• selections is an array with objects for each requested field of the Type
• the field name itself is buried under selections.name.value

The Hack

So what does all of this mean? Well with a couple of lines of code, a Model (from the context of course!), and the info argument, I wrote the following utility and proof of concept. It uses the Sequelize attributes property of the query object to get data only from the requested columns.

Using this utility resulted in a 94% decrease in the size of the query. This, of course, scales with the number of fields requested.

One of the major known benefits of using a GraphQL API is that it allows the front end to request a payload of the exact shape and size needed.

Using my utility allows the back end to reflect the same benefits by similarly reducing the load on the database server.

mapAttributes and proof of concept

The first and last lines of the mapAttributes function ensure only directly mapped Model fields are passed as attributes to the query object.

This prevents errors that arise from requesting fields that do not exist as columns on the Model.

These would arise from fields that require custom Type field resolvers (like Type relationships or custom Type field names).

Proof of Concept

User Type query: user(username:”the-vampiire”) { id }

before → all 17 fields of the User table are queried

SELECT "id", "role", "email", ...wtf Sequelize..., "timezone", "country_id", "city_id", "created_at", "updated_at" FROM "users" AS "User" WHERE "User"."github_username" = 'the-vampiire' LIMIT 1;

after → only the single requested field is queried

Executing (default): SELECT "status", "id" FROM "users" AS "User" WHERE "User"."github_username" = 'the-vampiire' LIMIT 1;

Caveats*

• I have not tested this with Mongoose or other popular OR/DMs, but in principle, the effect should be the same. The mapAttributes function and query object would just need a few customizations.
• I have not tested this with batch queries with different fields being requested (it may affect the fieldNodes property of info).
• Does not work with custom Type field resolvers for renamed fields
• The benefits will scale by the ratio of requested Type fields to total fields on the corresponding Model.

— Vamp
